Indoor Ceiling Antenna (800-2700)

Stadium /Office /Highway/ Railway /Scenic/ Pier /Island/ Offshore / Urban/ road /Supermarket /Metro/ Rural /Suburban/ Hospital/ Campus /Mine /Oilfield /Tunnel
• mode:KT-3C
• Product Category:Yagi Antenna
• Power supply:
• Frequency:885-909MHz/930-960MHz890-915MHz/935-960MHz1710-1785MHz/1805-1880MHz1850-1910MHz/1930-1990MHz1920-1980MHz/2110~2170MHz806 – 821MHz/851 - 866MHz2500-2570MHz/2620-2690MHz
  • Products Details
  • Company Profile
  • Introduction
  • Mainfeature
  • Application&scenarios
  • Specification
  • Parts/Warranty

Indoor Ceiling Antenna (800-2700) is designed for indoor wireless networks operating in the GSM/DCS/WCDMA/LTE...This wireless antenna is ideal for any indoor voice and data wireless system. Includes an N-style female connector and a ceiling mount.

Mainfeature

Frequency Range: 800-2700MHz
Polarization: V
Gain: 3±1dBi
Horizontal Beamwidth: 360°
Vertical Beamwidth: 60/30°
VSWR: ≤1.5
Dimension: 160x135x160mm

Application&scenarios

Specification

Electrical specifications

Model

KTTI-03-08/2.5V-E

Frequency Range

806-2500(MHz)

Input Impedance

50(Ω)

VSWR

<1.5

Gain

3(dBi)

(3dB)HPBW

360°

Maximum Power

50(W)

Polarization

Vertical Polarization

Connector Type

N-K

Ambient temperature

-40— +60

Mechanical specifications

Radom Material

ABS

Radom Colour

White

Diameter

Φ160(mm)

Height

90(mm)

Weight

0.3(kg)

Mounting Type

Chucking




Parts/Warranty
Warranty Period: 12months
