    Kingtone Indoor 5G CPE,Model:KT-R800-I,3GPP Release 15,802.11 b/g/a/n/ac/ax

    Stadium /Office /Highway/ Railway /Scenic/ Pier /Island/ Offshore / Urban/ road /Supermarket /Metro/ Rural /Suburban/ Hospital/ Campus /Mine /Oilfield /Tunnel
    • mode:KT-R800-I
    • Product Category:IoT Terminals
    • Power supply:
    • Frequency:
    • Products Details
    • Company Profile
    • Introduction
    • Mainfeature
    • Application&scenarios
    • Specification
    • Parts/Warranty

    Hight Performace 5G indoor CPE， support 5G NR/LTE‐ FDD/LTE‐ TDD/HSPA+，exchange the data between the 5G and WIFI/ethernet， support 4 giga LAN port, and LAN 4 could set to WAN port, support 2.4G+5G daul-mode WIFI-AP。This CPE could be used to quick net setting、WIFI hot point for family, small offfice and stores. It can be installed anywhere as you want and no need to install fiber network, so it is a flexible solution for broadband internet access solution.






    Mainfeature

    1.Net Support: NSA/SA/TDD-LTE/FDD- LTE/HSPA+
    2.Ethernet Port:4 *10/100/1000 Mbps,LAN4 Should be set to WAN port



    Application&scenarios

    WIFI hot point for family, small offfice and stores

    Specification

    HW Spec



    Main Chip

    Qualcomm: SDX55 Qualcomm: QCA6391

    Net Support

    NSA/SA/TDD-LTE/FDD- LTE/HSPA+

    Flash

    4 Gb 8-bit NAND

    Memory

    4Gb 16-bit LPDDR4

    Ethernet Port

    4 *10/100/1000 Mbps,

    LAN4 Should be set to WAN port

    USB

    USB3.1(Type C)

    LED

    9 LED Indicators(Power、

    WIFI 、 WPS 、 transmission 、Signal、4*Ethernets)

    SIM Card

    1*SIM (3FF) 1,8V& 3.0V

    Reset

    Set to default

    Ant.

    8*5G Ant.+2*WIFI Ant.

    Dimensions

    120*120*179mm

    Power Consumption

    < 24W

    Power Adapter

    DC 12V/2A

    Work Temerature

    -10℃--45℃

    Store Temerature

    -40℃--85℃



    5G Feature

    MIMO

    4*4MIMO

    Band Width

    5M, 10M, 15M, 20M, 25M,

    30M, 40M, 50M, 60M, 80M,

    90M, 100M

    5G NR Data Rate：

    1Gbps (UL), 4Gbps (DL)

    TX Power

    23±2 dBm

    Ant.

    Internal 8* Ant.

    Ant. Gain

    3-5 dBi

    TDD-LTE/FDD-LTE/HSPA+ Feature

    Frequence Support

    LTE-FDD B1/B2/B3/B4/B5/B7/B8/B12/B1 3/B14/B17/B18/B19/B20/B25/B

    26/B28/B29/B30/B66/B71 LTE-TDD

    B34/B38/B39/B40/B41/B42/B48 HSPA+

    B1/B2/B3/B4/B5/B8

    MIMO

    2*MIMO (2X2/4X2/8X2)

    TDD/FDD LTE DL

    Cat20+ : 2Gbps

    TDD/FDD LTE UL

    Cat20+ : 200Mbps

    TX Power

    23±2 dBm

    LTE ANT. Gain

    3-5 dB



    WIFI Feature


    3GPP Release 15 ，NSA&SA

    Frequence Support

    N1,N2,N3,N5,N7,N8,N12,N2 0,N25,N28,N40,N41,N66,N7

    1,N77,N78,N79

    Parts/Warranty
    12months for main unit ,6 months for accessories .
