    Baofeng / Pofung BF-9700 uhf Walkie Talkie Waterproof Two Way Radios

    Stadium /Office /Highway/ Railway /Scenic/ Pier /Island/ Offshore / Urban/ road /Supermarket /Metro/ Rural /Suburban/ Hospital/ Campus /Mine /Oilfield /Tunnel
    • mode:BF-9700
    • Product Category:Handheld Radio
    • Power supply:AC 110VAC 220VDC -48VDC-24V DV-12V AC 240
    • Frequency:
    • Products Details
    • Company Profile
    • Introduction
    • Mainfeature
    • Application&scenarios
    • Specification
    • Parts/Warranty

    BAOFENG BF-9700 Waterproof UHF Walkie Talkie transceiver is baofeng factory's first waterproof case radio.

    FM transceiver with extensive receive frequency coverage,providing local-area two-way amateur communications along with unmatched monitoring capability.


    Mainfeature

    Features:
    1) Output : 7W(H)/5W(M)/1W(L)
    2) Frequency Range: 136.00-174.00 MHz
    3) IP57 waterproof and dustproof
    4) High &Low Power Switchover
    5) Battery Saving
    6) VOX Function
    7) Wide/Narrow Band Selection
    8) Auto-Back Light
    9) Dual Band Standby
    10) Time-out Timer (TOT)
    11) 50 CTCSS and 104 DCS Codes
    12) Voice Prompt
    13) ANI Code
    14) PC or Manual Program
    15) DTMF Code
    16) PTT-ID
    17) ATUO Keypad Lock
    18) Busy Channel Lock Function
    19) Dual Band, Dual Display and Dual Standby
    20) Emergency Alarm
    21) Priory Scanning Function
    22) Relay Forwarding Confirmed (1750 HZ)
    23) Low Battery Warning
    24) U/V Cross Band Dual Watch

    Application&scenarios




    Specification

    Technical Specification :


    Frequency Range:

    VHF 136-174MHZ

    UHF 400.00- 520.00MHz

    Storage Channel

    16

    Step Frequency

    2.5 KHz,6.5 KHz,10 KHz,12.5 KHz,25 KHz

    Rated voltage

    DC 7.4V

    Frequency Stability

    ±2.5ppm

    Work Temperature

    -20 ℃ to +60℃

    Battery Capacity

    H-1800m Ah (Li-ion Battery)

    Battery Life

    About 12 Hours

    Frequency Combination

    PLL frequency synthesis

    Antenna Impedance

    50 Ω

    Wok Mode

    Same Frequency simplex Operation or Different Frequency simplex Operation

    Dimension

    135(H)*64(W)*40(D)mm (Excluded Antenna)

    Transmitter

    Output Power

    7W(H)/5W(M)/1W(L)

    Modulation Mode(W/N Band)

    16KΦF3E

    Maximum Frequency Deviation (W/N Band)

    ≤5 KHz

    Spurious Power

    ≤7.5 µW

    Adjacent channel power

    ≤-65dB/≤-60dB

    Audio Distortion

    <5 %

    SNR

    ≥-45dB/≥-40dB

    CTSCC/DCS Frequency Deviation(W/N Band)

    0.7±0.1KHz (W), 0.4±0.1KHz (N)

    Modulation Sensitivity

    8-12mV

    Transmitting Current

    ≤1500mA

    Receiver

    Sensitivity

    <0.20 µ V (12dB SINAD)

    Audio Power

    >2W@10%

    Inter modulation Interference Resistance

    ≥65dB (W), ≥55dB (N)

    Adjacent channel Sensitivity (W/N Band)

    ≥65dB (W), ≥55dB (N)

    Audio Distortion

    5 %

    Receiving Current

    ≤ 380m A

    Parts/Warranty



    1*Host (BF-9700 UHF 400-470Mhz)

    1*7.4V 1800mah Li-ion Battery Pack

    1* Antenna

    1* Belt Clip

    1* Use's Manual

    1*Desktop Charger ( 100V-240V )+(2pin USA or 3pin UK or 2pin EURO or 2pin Australia)
